Máquina formadora de vasos de papel
Descripción de la máquina formadora de vasos de papel:
La máquina formadora de vasos de papel se usa para producir vasos de papel, puede usarla para hacer vasos de diferentes tamaños para cafeterías, restaurantes o domésticos. Para diferentes tamaños, debe cambiar diferentes moldes, una máquina debe estar equipada con un molde.
Parámetro técnico de la máquina formadora de vasos de papel:
Modelo:MJ-C12H
Paper Cup Size RANGE: 2 12OZ
Velocidad: 90100pc/min
Diámetro superior del vaso de papel: Mín. 45 mm Máx. 104 mm
Diámetro inferior del vaso de papel: Mín. 35 mm Máx. 75 mm
Altura del vaso de papel: Mín. 35 mm Máx. 115 mm
Raw material: 180350gsm, single or double PE coating paper
General power: 11 Kw
Electricity: 380V 3 phases
Air consumption: 0.2 cbm/min
Weight: 3000 kg
Característica de la máquina formadora de vasos de papel:
1. Paper cup bottom sealing by Bank Brand,original switzerland hot air ceramic heating core.
2. It is easy to make cups of different size by changing moulds.
3. Cup side sealing by ultrasonic.
4. Double PE coating paper cups for cold drink as well as hot drink.
5. With our unique original designed bottom knurling system, single shaft, Korea type, this ensures the low leaking ratio and high quality of paper cups.
6. With unique single shaft design, the drive system is conducted by the stable gear system,it would be more stable when machine running at a high speed.
7. With automatic lubricating system, it will automatic lubricating to every moving parts when machine runs.
8. Every cam will be harden to ensure it can run for a long long time.
9. Machine is designed with double turning plate
10. Equipped with automatic cup collecting stacking and counting system.
11. Bottom paper we have a special pre-feeding system, so the bottom paper feeding is "0" waste.
12. Adopt the SIEMENS PLC micro computer system and also equipped with SIEMENS touch screen for easy and visible operation.
13. The upgraded gear box for longer life span.
14. Optional quality checking system
Paquete de máquina formadora de vasos de papel:
Producto relacionado de la máquina formadora de vasos de papel:
Nuestro servicio de máquina formadora de vasos de papel:
We will, without charge, offer replacement for defective parts which is caused by product quality in one year. Lifelong service is offered with cost charge after one year.And we can send technician for installation and training at the cost of buyer.
Si está interesado, bienvenido a contactarnos!
